Table:
Workbench area: 6000 × 2800 mm
Workbench load-bearing: 28000 kg/m²
Table T-slot (slot width × slot number): 28 × 11 mm

Travel:
X travel: 6300 mm
Y travel: 3500 mm
Z travel: 1500 mm
Distance between columns (gantry width): 3300 mm
Spindle nose to table surface distance: 350 ~ 1850 mm

Spindle:
Spindle taper: ISO No. 50
Main motor power (continuous / 30 min):
SIEMENS: 30 / 38 kW
FANUC: 26 / 30 kW
Spindle speed: 3000 rpm (optional 4500 / 6000 rpm)

Feed Rate:
Cutting feed rate: 5 m/min
Rapid traverse: 10 m/min

Automatic Tool Changer:
Tool magazine type: Robot
Tool holder specification: BT-50
Tool magazine capacity: 40
Maximum tool diameter / adjacent empty: φ125 / φ200 mm
Maximum tool length: 400 mm
Maximum tool weight: 20 kg

Accuracy:
Positioning accuracy (X / Y / Z): 0.03 / 0.025 / 0.025 mm
Repeatability (X / Y / Z): 0.02 / 0.015 / 0.01 mm

Machine Dimensions & Weight:
Dimensions: 14910 × 6510 × 6785 mm
Machine weight: 88 T

Accessories:
Optional milling heads: Right angle milling head, universal milling head, milling head extension, special milling head
Available options: Accessories milling head and overall protective cover
